About This Item
Description
Dwyer 475-7-FM Handheld digital manometer, range 0-100.0 psi (6.895 bar), max. pressure 150 psig.
- New Low Range Option 0-1.000 in. w.c.
- Measures Positive, Negative and Differential Pressures
- Rugged, Extruded Aluminum Case
- Lightweight, Fast and Easy to Use
- Selectable English/Metric Units
- FM Approved
- Service: Air and compatible combustible gases.
- Accuracy: ±0.5% F.S., 60 to 78°F (15.6 to 25.6°C); ±1.5% F.S. from 32 to 60°F and 78 to 104°F (0 to 15.6°C and 25.6 to 40°C).
- Pressure Hysteresis: ±0.1% of full scale.
- Pressure Limits: See Ordering page.
- Temperature Limits: 0 to 140°F (-17.8 to 60°C).
- Compensated Temperature Limits: 32 to 104°F (0 to 40°C).
- Storage Temperature Limits: -4 to 176°F (-20 to 80°C).
- Display: 0.42" (10.6 mm) 4-digit LCD.
- Resolution: See Ordering page.
- Power Requirements: 9 volt alkaline battery. Battery not connected.
- Weight: 10.8 oz. (306 g).
- Connections: Two barbed connections for use with 1/8" (3.18 mm) or 3/16" (4.76 mm) I.D. tubing. Two compression fittings for use with 1/8" (3.18 mm) I.D. x 1/4" (6.35 mm) O.D. tubing for 475-7-FM & 475-8-FM only.
- Agency Approvals: FM, CE.
